ZMN2405DK
?
?
Simple to set-up and configure
Complete with all components to put a system “on the air”
?
?
?
?
Accelerates the integration process
Full technical support included with purchase
Allows development of interface to your system
Allows development of your control software
ZigBee ?
Developer’s Kit
The ZMN2405DK Developer ’s Kit comprises two high power serial interface boards built around the
1mW ZigBee ZMN2405 module. The ZMN2405DK allows developers to get up and running quickly
using either USB or RS-232 interfaces.
The self-contained modems have momentary switches, LEDs, thermister, and potentiometer and can
operate on standard 9V akaline batteries. This provides a simple, effective way to test the range and
operation of the radios in the real-time environment. The onboard I/O can be disconnected, allowing
user inputs to be connected to the module inputs using connectors. The ZBDemo program included on
the supplied CD allows the reading and writing of end device inputs and outputs as well as network
discovery and configuration. If your individual wireless requirements could benefit from the application
of ZigBee technology, the ZMN2405DK is the premier first step.
The ZMN2405DK should also be selected for those wishing to use RFM ZMN2430 module.
www.RFM.com E-mail: info@rfm.com
?2008 by RF Monolithics, Inc.
D e v e l o p e r’ s K i t s C o n t e n t s
? 2 ea. evaluation boards
? 2 ea. AC power adapters and
cords
? 2 ea. patch antennas
? 2 ea. USB cables
? 2 ea. serial cables
? 2 ea. RF cables
? 2 ea. omni antennas
? 2 ea. 9V batteries
? 1 ea. software CD
Page 1 of 1
ZMN2405DK - 3/18/08
